1,Module standardization: lation,intelligent and IOT optional,easy upgrade,matching with JUNHE® standard curing furnace. modular,standardized design,connect with electric cabinet,whole machine assembly,easy instal-
2,High efficiency: liquid retention in blind-hole parts, robotic dual-basket handling for higher efficiency. Low-speed material homogenization,high-speed centrifugation, tilted tumbling for uniform coating, less
3,Excellent safety and environmental friendly: air,suitable for water-base and solvent-base paint. Anti-splashing coating, overall enclosed, centralized collection of exhaust
4,Excellent batch management: automatic operation,can monitor the whole process. No risk of parts stuck. each batch of workpiece weighing according to the process requirements,the whole process
5,A wide range of module options are available: module, unloading module, paint constant temperature module, paint control and detection module, exhaust gas treatment coating machine module, loading module, weighing module, anti-collision
module, standardization and modularization of vulnerable parts. Plug-and-play between modules enhances flexibility and
3.Technical Parameter
Basket diameter | Ø800×450mm | Max loading capacity | 180kg/basket |
Shortest production cycle | 180s | Capacity | M10x50mm full-thread bolts) |
Max centrifugal speed | 320r/min | Exhaust gas collection rate | 95% |
Max tilting angle | 60° | Effusion rate control | ＜5‰ |
Machine size | 2550×2250×3280mm | Total power | ≤30kw(excluding the robot) |
Suitable furnace | Junhe mesh belt curing furnace,stepping tray-type curing turnace | Suitable paint | All types water-base and solvent-base paint |
Suitable workpieces | ≤200mm external and internal hexagon bolts,cross bolts,nuts,stamping parts |
